Colour: Milk /Transport/blue
PC Sheet: thickness: 0.5-15mm ,Format 122:0*2440mm
Thickness :20-120mm Format 600*1200/1000*2000mm
PC Rod Diameter: 0.5-380mm, length: 1000-3000mm
It is a kind of amorphous,odorless,non-toxic,highly transparent colorless or yellowish thermoplastic engineering plastics,has been hailed as a transparent metal. PC sheets has the features of high mechanical strength,good creep resistance even at low temperature,high impact strength,in a large temperature range has a rigid retention,energy radiation resistance,good electrical insulation,good dimensional stability,translucency,physiological inertia,suitable for contact with food.
Used in machinery,electronics,automobile,construction,household items,hand-board model etc..and is rapidly expanded to aviation,aerospace,computer,CD,optical fiber and many other high-tech fields.
| Heat transfer coefficient | W/m² ºC | 0.21 |
| Resistant temperature | ºC | -40ºC~+120ºC |
| tensile strength | n/mm² | ≥60 |
| Bending strength | n/mm² | 100 |
| Elastic Modulus | MPA | 2400 |
| Tensile stress | MPA | ≥130 |
| Elongation at break | % | ≥130 |
| Sound insulation | db | Outdoor billboards |
| Item | Width | Thickness | Colour | Soundproof Index | Minimun bending |
| PC | 1220 | 1.5 | Milk | 270 | |
| 1560 | 2.0 | Tea | 360 | ||
| 1820 | 2.4 | Transparent | 430 | ||
| 2100 | 3.0 | blue | 540 | ||
| 3.8 | green | 680 | |||
| 4.0 | 0.9 | 720 | |||
| 5.0 | 1.1 | 900 | |||
| 6.0 | 1.3 | 1080 | |||
| 8.0 | 1.6 | 1450 |
