Colour: Milk /Transport/blue
PC Sheet: thickness: 0.5-20mm ,Format 122:0*2440mm
Thickness :20-120mm Format 600*1200/1000*2000mm
PC Rod Diameter: 0.5-380mm, length: 1000-3000mm
It is a kind of amorphous,odorless,non-toxic,highly transparent colorless or yellowish thermoplastic engineering plastics,has been hailed as a transparent metal. PC sheets has the features of high mechanical strength,good creep resistance even at low temperature,high impact strength,in a large temperature range has a rigid retention,energy radiation resistance,good electrical insulation,good dimensional stability,translucency,physiological inertia,suitable for contact with food.
Used in machinery,electronics,automobile,construction,household items,hand-board model etc..and is rapidly expanded to aviation,aerospace,computer,CD,optical fiber and many other high-tech fields.
| Heat transfer coefficient | W/m² ºC | 0.21 |
| Resistant temperature | ºC | -40ºC~+120ºC |
| tensile strength | n/mm² | ≥60 |
| Bending strength | n/mm² | 100 |
| Elastic Modulus | MPA | 2400 |
| Tensile stress | MPA | ≥130 |
| Elongation at break | % | ≥130 |
| Sound insulation | db | Outdoor billboards |
| Item | Width | Thickness | Colour | Soundproof Index | Minimun bending |
| PC | 1220 | 1.5 | Milk | 270 | |
| 1560 | 2.0 | Tea | 360 | ||
| 1820 | 2.4 | Transparent | 430 | ||
| 2100 | 3.0 | blue | 540 | ||
| 3.8 | green | 680 | |||
| 4.0 | 0.9 | 720 | |||
| 5.0 | 1.1 | 900 | |||
| 6.0 | 1.3 | 1080 | |||
| 8.0 | 1.6 | 1450 |
1. Q: What color can you make?
A: Usually we can make the regular color, like green, blue, black, yellow, grey and so on. Or you can offer the pantone color number for reference to produce.
2.Q: What is your MOQ?
A: It depends on the drawing.
3. Q: What is your delivery time?
A: It depends on the volume, usually it is about 7 days.
4. Q: How can I get a sample?
A: Small size of sample are free, you only need to pay for the shipping cost, or you can provide your UPS, DHL, Fedex, TNT courier account to us. Customized size of sample should be charged.
5. Q: What is your payment ?
A:30% T/T in advance, balance before shipment. Other terms negotiable.
