Colour :transport
PMMA sheet :thickness :1-120M
Size:600*1200/1000*2000mm/1220*2440mm and customization
PMMA tube:OD5-1500mm,Length:1000-3000mm
The PMMA tubes stand for Poly Methyl MethAcrylate, and it is also known as acrylic or acrylic glass. In the business world, or trade language PMMA tube is known as; Plexiglas, Lucite, Crylux, Acrylite, and Perspex among several others. The PMMA tube is generally considered one of the clearest plastics in the market.
PMMA is a transparent thermoplastic, it is generally used in sheet form being a trivial or shatter-resistant alternative to glass. On the other hand, it can also be used in inks, as a casting resin, coatings, and has many other uses.
PMMA is an amorphous, transparent and colorless thermoplastic that is hard and stiff, yet brittle and notch-sensitive. It has great scraped area and UV protection and astounding optical clearness however poor low temperature, weakness, and solvent resistance. Though flammable, it has a low smoke emission.
| Product Features | ||
| • Good Optical Properties | • Thermoformable | |
| • Versatile, suitable for Fabrication | • Excellent sound abatement properties | |
| • UV Stabilised | • Easy to machine | |
| • Impact Resistant |
| Product Applications | ||
| • Aquarium | • Models | |
| • Furniture | • Lighting | |
| • Cake stands | • Graphic Arts | |
| • Exhibits | • Medical | |
| • Signage |
| Acrylic Extruded Tube with any size | ||||||||
| OD(mm) | OD(mm) | OD(mm) | OD(mm) | OD(mm) | OD(mm) | OD(mm) | OD(mm) | OD(mm) |
| Φ5 | ?14 | Φ25.4 | Φ37.5 | Φ56 | Φ71 | Φ88.3 | Φ130 | Φ200 |
| Φ6 | ?15 | Φ26 | Φ38 | Φ57 | Φ72 | Φ89 | Φ135 | Φ203.2 |
| Φ7 | ?16 | Φ26.5 | Φ39 | Φ57.2 | Φ72.6 | Φ90 | Φ140 | Φ210 |
| Φ8 | 16.5 | Φ27 | Φ40 | Φ58 | Φ73 | Φ95 | Φ145 | Φ220 |
| Φ9 | ?17 | Φ28 | Φ42 | Φ60 | Φ75 | Φ100 | Φ146 | Φ230 |
| Φ9.5 | ?18 | Φ30 | Φ44.5 | Φ62 | Φ76 | Φ101.6 | Φ150 | Φ240 |
| Φ10 | Φ19 | Φ31 | Φ45 | Φ63 | Φ77 | Φ105 | Φ152.4 | Φ250 |
| Φ10.5 | Φ20 | Φ31.8 | Φ48 | Φ63.5 | Φ80 | Φ110 | Φ155 | Φ280 |
| Φ11 | Φ21 | Φ32 | Φ50 | Φ64 | Φ82 | Φ114 | Φ160 | Φ300 |
| Φ12 | Φ22 | Φ33 | Φ50.8 | Φ65 | Φ84 | Φ115 | Φ165 | Φ320 |
| Φ12.5 | Φ23 | Φ34 | Φ51 | Φ68.5 | Φ85 | Φ120 | Φ170 | Φ350 |
| Φ12.7 | Φ24 | Φ35 | Φ52 | Φ69 | Φ86 | Φ125 | Φ178 | Φ400 |
| Φ13 | Φ24.5 | Φ36 | Φ54 | Φ69.5 | Φ87 | Φ127 | Φ180 | |
| Φ13.5 | Φ25 | Φ37 | Φ55 | Φ70 | Φ88 | Φ129.5 | Φ190 | |
| Casting Acrylic Tube with 2 Meters length | ||||||||
| OD(mm) | OD(mm) | OD(mm) | OD(mm) | OD(mm) | OD(mm) | OD(mm) | OD(mm) | OD(mm) |
| Φ50 | Φ85 | Φ130 | Φ180 | Φ250 | Φ305 | Φ380 | Φ500 | Φ629 |
| Φ55 | Φ90 | Φ140 | Φ190 | Φ260 | Φ310 | Φ400 | Φ528 | Φ650 |
| Φ60 | Φ95 | Φ145 | Φ200 | Φ270 | Φ320 | Φ403 | Φ532 | Φ700 |
| Φ65 | Φ100 | Φ150 | Φ210 | Φ280 | Φ328 | Φ420 | Φ556 | Φ780 |
| Φ70 | Φ110 | Φ160 | Φ220 | Φ285 | Φ350 | Φ450 | Φ579 | Φ800 |
| Φ75 | Φ120 | Φ165 | Φ230 | Φ290 | Φ352 | Φ454 | Φ600 | Φ900 |
| Φ80 | Φ125 | Φ170 | Φ240 | Φ300 | Φ360 | Φ478 | Φ606 | Φ1000 |
| Casting Acrylic Tube with 3Meters length | ||||||||
| OD(mm) | OD(mm) | OD(mm) | OD(mm) | OD(mm) | OD(mm) | OD(mm) | OD(mm) | |
| Φ200 | Φ300 | Φ450 | Φ555 | Φ700 | Φ828 | Φ1000 | Φ1500 | |
| Φ250 | Φ400 | Φ500 | Φ600 | Φ800 | Φ900 | Φ1200 | ||
1. Q: What is your delivery time?
A: It depends on the volume, usually it is about 7 days.
2. Q: How can I get a sample?
A: Small size of sample are free, you only need to pay for the shipping cost, or you can provide your UPS, DHL, Fedex, TNT courier account to us. Customized size of sample should be charged.
3. Q: What is your payment ?
A:30% T/T in advance, balance before shipment. Other terms negotiable.
