MOQ:
Default
Port:
Hangzhou
Packaging:
Customizable
Lead Time:
Default
Size:
Default Size
Color:
Default Color
Color:White,Black,Blue and so on.
Size:1000X2000X(Thickness:1-200mm),1220X2440X(Thickness:1-200mm)
600X1200X(Thickness:1-200mm)
Data Sheet
| Property | Item No. | Unit | POM-C | POM-H | POM-H+PTFE | |
| Mechanical Properties | 1 | Density | g/cm3 | 1.41 | 1.43 | 1.50 |
| 2 | Water absorption(23ºC in air) | % | 0.20 | 0.20 | 0.17 | |
| 3 | Tensile strength | MPa | 68 | 78 | 55 | |
| 4 | Tensile strain at break | % | 35 | 35 | 10 | |
| 5 | Compressive stress(at 2%nominal strain) | MPa | 35 | 40 | 37 | |
| 6 | Charpy impact strength (unnotched) | KJ/m2 | ≥150 | ≥200 | ≥30 | |
| 7 | Charpy impact strength (notched) | KJ/m2 | 7 | 10 | 3 | |
| 8 | Tensile modulus of elasticity | MPa | 3100 | 3600 | 3200 | |
| 9 | Ball indentation hardness | N/mm2 | 140 | 160 | 140 | |
| 10 | Rockwell hardness | - | M84 | M88 | M84 | |
POM resins (polyoxymethylene or POM) are engineering thermoplastics based on formaldehyde polymerization technology. POMresins have high tensile strength, stiffness, resilience, fatigue endurance, a low coefficient of friction against metals, POM and other plastics and moderate toughness. The polyoxymethylene sheet has high resistance to organic solvents, excellent dimensional stability, a low coefficient of friction and outstanding abrasion resistance among thermoplastics.
polyoxymethylene resistance to creep is excellent. Moisture, lubricants and solvents have little effect on this property, which is important in parts incorporating self-threading screws or interference fits. Good electrical properties qualify these materials for electrical applications requiring long-term stability. POM copolymers retain much of their toughness through a broad temperature range and are among the most creepresistant of the crystalline thermoplastics. A low moisture absorption characteristic permits molded parts to serve reliably in environments involving humidity variations.
1. Q: What color can you make?
A: Usually we can make the regular color, like green, blue, black, yellow, grey and so on. Or you can offer the pantone color number for reference to produce.
2.Q: What is your MOQ?
A: 100KGS.
3. Q: What is your delivery time?
A: It depends on the volume, usually it is about 7 days.
4. Q: How can I get a sample?
A: Small size of sample are free, you only need to pay for the shipping cost, or you can provide your UPS, DHL, Fedex, TNT courier account to us. Customized size of sample should be charged.
5. Q: What is your payment ?
A:30% T/T in advance, balance before shipment. Other terms negotiable.
